Grass Valley LDX 100 Studio Camera

The Grass Valley LDX 100 is a UHD (3840x2160) per imager 2/3 inch cinema camera — with UHD 3840x2160 video. Check GearFocus for current availability, with buyer protection on every purchase.

Grass Valley LDX 100 Studio Camera

Grass Valley LDX 100 Studio Camera

Get notified when one lists.

We'll text or email you the moment a Grass Valley LDX 100 Studio Camera is listed on GearFocus.

Have a Grass Valley LDX 100 sitting in your bag?

You'd be the first listing for this model.
Serious buyers are already watching — list yours in minutes.

Sell your Grass Valley LDX 100 on GearFocus

Camera Overview — Grass Valley LDX 100

The Grass Valley LDX 100 is a flagship studio camera built for demanding professional broadcast and live production environments. At its core is a 2/3-inch sensor delivering UHD resolution at 3840x2160, processed through Grass Valley's proprietary Xenios platform image processor. The camera supports an impressive range of frame rates — 24fps, 25fps, 30fps, 50fps, 60fps, 120fps, and up to 180fps — making it a capable tool for high-speed UHD capture in live broadcast scenarios.

Video output is 10-bit, with color profile support spanning HDR formats including HLG, PQ, and S-Log3, as well as SDR and Wide Color Gamut options, giving colorists and broadcast engineers meaningful flexibility in delivery workflows. The camera uses a B4 lens mount, standard in professional broadcast production, and is designed for external studio power rather than onboard battery operation. Build quality centers on ruggedized metal and composite construction with weather sealing, and the body weighs in at 2.9kg with dimensions of 380 x 167 x 253mm.

An optional EyeCatcher EC 2-100 LCD viewfinder with 960x540 resolution and 60Hz refresh rate is available, and the camera also features a 7-inch 1920x1080 LCD display. No internal storage media is included, consistent with its studio-integrated workflow design.

Key Features — Grass Valley LDX 100

2/3-Inch UHD Sensor: Captures at 3840x2160 resolution on a 2/3-inch imager, the standard sensor format for professional broadcast studio cameras.

Xenios Image Processor: Grass Valley's proprietary processing platform handles UHD signal processing and color science for broadcast-grade image quality.

180fps High-Speed Capture: Records up to 180fps at UHD resolution, enabling high-speed slow-motion content within a live broadcast workflow.

10-Bit Video Output: 10-bit signal output provides the color depth needed for professional grading and broadcast delivery pipelines.

HDR & Wide Color Gamut Support: Supports HLG, PQ, and S-Log3 color profiles alongside SDR and Wide Color Gamut, covering a broad range of broadcast and streaming delivery standards.

B4 Lens Mount: Industry-standard broadcast mount accepts a wide ecosystem of 2/3-inch ENG and studio lenses from major manufacturers.

Camera Specifications — Grass Valley LDX 100

Grass Valley LDX 100 full specifications
SpecDetail
TypeOther
Sensor2/3 inch
ResolutionUHD (3840x2160) per imager
ProcessorGrass Valley proprietary (Xenios platform)
AF SystemManual Focus Only
Max Video ResolutionUHD 3840x2160
Max Frame Rate180fps
Bit Depth10-bit
Video Color ProfilesHDR (HLG, PQ, S-Log3), SDR, Wide Color Gamut
Image StabilizationNone
Display7 inches LCD
Display Resolution1920x1080

Description — Grass Valley LDX 100

The Grass Valley LDX 100 is a professional studio camera built around a 2/3-inch sensor capable of capturing UHD 3840x2160 resolution, processed through the Grass Valley Xenios platform image processor. Video is recorded at 10-bit depth, with color profile options that include HLG, PQ, S-Log3, SDR, and Wide Color Gamut — a comprehensive set for modern broadcast HDR workflows. Frame rate flexibility is a standout characteristic, with support for 24fps, 25fps, 30fps, 50fps, 60fps, 120fps, and 180fps, covering everything from standard broadcast to high-speed production.

The camera uses a B4 lens mount, consistent with professional broadcast standards. The body is constructed from ruggedized metal and composite materials with weather sealing, measures 380 x 167 x 253mm, and weighs 2.9kg. Monitoring is handled by a 7-inch 1920x1080 LCD display, with an optional EyeCatcher EC 2-100 LCD viewfinder offering 960x540 resolution at 60Hz.

Studio power is required — no onboard battery is included — and the camera has no internal storage media, positioning it firmly within integrated broadcast infrastructure workflows.

Pros — Grass Valley LDX 100

  • ✓UHD 3840x2160 sensor resolution with 10-bit video output for high-quality broadcast capture
  • ✓High-speed frame rate support up to 180fps, with additional options at 24, 25, 30, 50, 60, and 120fps
  • ✓Broad HDR color profile support including HLG, PQ, S-Log3, and Wide Color Gamut

Cons — Grass Valley LDX 100

  • ✗Relies entirely on external studio power — no onboard battery option for field or portable use
  • ✗No internal storage media, requiring external recording infrastructure
  • ✗No built-in WiFi or Bluetooth connectivity

Resources & Downloads — Grass Valley LDX 100

Manuals & Guides

Frequently Asked Questions — Grass Valley LDX 100

What lens mount does the LDX 100 use?+
The LDX 100 uses a B4 lens mount, which is the standard mount found on professional broadcast studio cameras. This makes it compatible with the broad ecosystem of B4-mount broadcast lenses available for studio and live production.
What HDR formats does the LDX 100 support?+
The camera supports HLG, PQ, and S-Log3 HDR color profiles, as well as SDR and Wide Color Gamut. This range of options provides flexibility for broadcast delivery pipelines that require different HDR standards.
What is the maximum frame rate available on the LDX 100?+
The LDX 100 supports a maximum frame rate of 180fps. Additional frame rate options include 24fps, 25fps, 30fps, 50fps, 60fps, and 120fps, covering a wide range of broadcast and high-speed production needs.
Does the LDX 100 have a viewfinder?+
The camera supports an optional EyeCatcher EC 2-100 LCD viewfinder with a resolution of 960x540 and a 60Hz refresh rate. It also includes a built-in 7-inch LCD display at 1920x1080 resolution.
What image processor does the LDX 100 use?+
The LDX 100 is powered by Grass Valley's proprietary Xenios platform image processor. This is the processing engine behind the camera's UHD imaging and high-speed frame rate capabilities.
Does the LDX 100 work on battery power?+
No — the LDX 100 is designed exclusively for external studio power and does not include an onboard battery or battery life rating. It is intended for fixed studio and live broadcast installations where continuous external power is available.
