JVC GY-HM170 4KCAM Professional 4K Camcorder

The JVC GY-HM170 is a 12.4 MP 1/2.3 inch cinema camera — with 4K video. Check GearFocus for current availability, with buyer protection on every purchase.

JVC GY-HM170 4KCAM Professional 4K Camcorder

JVC GY-HM170 4KCAM Professional 4K Camcorder

Get notified when one lists.

We'll text or email you the moment a JVC GY-HM170 is listed on GearFocus.

Have a JVC GY-HM170 sitting in your bag?

You'd be the first listing for this model.
Serious buyers are already watching — list yours in minutes.

Sell your JVC GY-HM170 on GearFocus

Camera Overview — JVC GY-HM170

The JVC GY-HM170 4KCAM is a professional camcorder built around a 1/2.3-inch sensor with a 12.4 MP resolution, capable of recording up to 4K maximum video resolution. It supports a range of frame rates including 24fps, 30fps, 60fps, and up to 120fps, with 8-bit color depth and color profile options spanning Standard, Cinema, and Custom modes — giving videographers meaningful control over the look of their footage without requiring post-production color grading from scratch.

The camcorder features Optical Image Stabilization (OIS), helping to reduce camera shake during handheld or run-and-gun shooting scenarios. For monitoring and composition, it includes a 3.5-inch LCD display at 920,000 pixels alongside an LCD viewfinder rated at 1.56 million pixels — a meaningful resolution bump over the rear screen for critical focus work.

Audio connectivity is a notable strength, with a 3.5mm microphone jack supplemented by two XLR inputs, making it compatible with professional microphones and audio equipment right out of the box. A Full HDMI output enables clean external monitoring or direct feed to a recorder. Storage is handled via SDHC and SDXC cards. The body weighs 1.11 kg and measures 153 x 112 x 299 mm, and the included BN-VF823 battery provides approximately 2 hours and 20 minutes of runtime.

Key Features — JVC GY-HM170

4K Video Recording: Records up to 4K resolution; high frame rate options are available at lower resolutions, not at 4K.

1/2.3-Inch 12.4MP Sensor: A 12.4MP 1/2.3-inch sensor captures detailed 4K video in a compact, lightweight camcorder body.

Dual XLR Audio Inputs: Two XLR inputs plus a 3.5mm microphone jack allow direct connection of professional-grade microphones and audio equipment without an external adapter.

Optical Image Stabilization: Built-in OIS reduces camera shake during handheld or run-and-gun shooting, helping maintain usable footage without a rig or gimbal.

Electronic Viewfinder: A high-resolution electronic viewfinder aids critical focus evaluation in bright conditions where the rear LCD is difficult to read.

3.5-Inch Rear LCD: A 920,000-pixel articulating LCD monitor aids framing and playback review in a variety of shooting positions.

Camera Specifications — JVC GY-HM170

JVC GY-HM170 full specifications
SpecDetail
Use CasesDocumentary
TypeOther
Sensor1/2.3 inch
Resolution12.4 MP
AF SystemContrast Detection
Max Video Resolution4K
Max Frame Rate60fps
Bit Depth8-bit
Video Color ProfilesStandard, Cinema, Custom
Image StabilizationOptical (OIS)
Display3.5 inches LCD
Display Resolution920,000 pixels

Description — JVC GY-HM170

The JVC GY-HM170 4KCAM is a professional camcorder featuring a 1/2.3-inch sensor with 12.4 MP resolution and 4K maximum video output. It records at frame rates of 24fps, 30fps, 60fps, and 120fps with 8-bit color depth, and offers three selectable color profiles — Standard, Cinema, and Custom — for creative flexibility.

For monitoring, the camera provides a 3.5-inch, 920,000-pixel LCD rear display alongside a 1.56-million-pixel LCD viewfinder. Optical Image Stabilization (OIS) helps manage camera movement during handheld operation. A Full HDMI output supports external monitors or recorders, while audio options include a 3.5mm mini jack and two XLR inputs for professional microphone connectivity.

Files are stored on SDHC or SDXC cards. The body weighs 1.11 kg and measures 153 x 112 x 299 mm. The included BN-VF823 battery delivers approximately 2 hours and 20 minutes of use. Weather sealing is not present, so users should account for environmental protection in outdoor shoots.

Pros — JVC GY-HM170

  • ✓4K maximum video resolution with frame rate options up to 120fps
  • ✓Dual XLR inputs plus a 3.5mm mic jack for professional audio connectivity
  • ✓Optical Image Stabilization (OIS) for smoother handheld footage

Cons — JVC GY-HM170

  • ✗No weather sealing, limiting use in rain or dusty outdoor environments
  • ✗8-bit color depth only, which restricts dynamic range headroom in post-production
  • ✗No Wi-Fi or Bluetooth connectivity for wireless file transfer or remote control

Videos — JVC GY-HM170

Review: JVC GY-HM170 / GY-HM200 4K camcorder — TubeShooterMag

Resources & Downloads — JVC GY-HM170

Manuals & Guides

Frequently Asked Questions — JVC GY-HM170

What frame rates does the JVC GY-HM170 support?+
The GY-HM170 supports 24fps, 30fps, 60fps, and up to 120fps according to its video specifications. The maximum frame rate is listed as 120fps.
Does the GY-HM170 accept professional XLR microphones?+
Yes. The camcorder includes two XLR inputs as well as a 3.5mm mini microphone jack, making it compatible with professional-grade audio equipment without an external adapter.
What storage media does the GY-HM170 use?+
The camcorder records to SDHC and SDXC memory cards. No proprietary storage format is required.
Does the GY-HM170 have weather sealing?+
No. The bodyDesign specifications explicitly list weather sealing as 'None,' so the camera should be protected from rain and dust during outdoor use.
What does the LCD viewfinder resolution look like compared to the rear screen?+
The built-in LCD viewfinder is rated at 1.56 million pixels, while the 3.5-inch rear LCD display offers 920,000 pixels — making the viewfinder notably sharper for critical focus and framing work.
How long does the included battery last?+
The included BN-VF823 battery provides approximately 2 hours and 20 minutes of runtime, as listed in the battery specifications.
