Kinefinity KineRAW Cinema Camera

The Kinefinity KineRAW-MINI is a 2048 x 1080 (2.2 megapixels effective) Super 35 cinema camera — with 2048 x 1080 (2K DCI) video. Check GearFocus for current availability, with buyer protection on every purchase.

Kinefinity KineRAW Cinema Camera

Kinefinity KineRAW Cinema Camera

Get notified when one lists.

We'll text or email you the moment a Kinefinity KineRAW Cinema Camera is listed on GearFocus.

Have a Kinefinity KineRAW-MINI sitting in your bag?

You'd be the first listing for this model.
Serious buyers are already watching — list yours in minutes.

Sell your Kinefinity KineRAW-MINI on GearFocus

Available Now on GearFocus

Kinefinity TERRA 4K Cinema Camera Package
Deal
KinefinityLike New

Kinefinity TERRA 4K Cinema Camera Package

$3,149.99$3,949.00-20% OFF

Camera Overview — Kinefinity KineRAW-MINI

The Kinefinity KineRAW is a Super 35 cinema camera built around a 2048 x 1080 (2K DCI) sensor delivering 2.2 megapixels of effective resolution. With a native ISO range spanning 80 to 20480, the camera is designed to handle a wide variety of lighting conditions on set. It records at 12-bit depth and supports an extensive range of frame rates including 23.976, 24, 25, 29.97, 30, 48, 50, 59.94, 60, 96, and 100fps, giving cinematographers meaningful slow-motion options at higher frame rates.

Color science is handled through four selectable profiles — KineLOG, Kine709, KineColor, and user-defined LUT support — providing flexibility for both on-set monitoring and post-production grading workflows. The camera uses a PL mount, aligning it naturally with a broad ecosystem of professional cinema glass. Storage is handled via SSD.

Connectivity includes two HDMI outputs for 720p monitoring, a 3.5mm microphone jack (without phantom power), and Wi-Fi. Focus is entirely manual. Power comes via an optional handgrip with battery or DC IN accepting 6 to 19V, with the body weighing 1,500g and measuring 94 x 118 x 168mm.

There is no in-body or digital image stabilization.

Key Features — Kinefinity KineRAW-MINI

Super 35 2K DCI Sensor: 2048 x 1080 native resolution sensor in a Super 35 form factor, matching the framing and depth-of-field characteristics familiar to cinema workflows.

12-Bit RAW Recording: Records 12-bit depth to SSD, providing substantial latitude for color correction and grading in post-production.

ISO 80–20480 Range: Wide native ISO range allows the camera to be used across a broad spectrum of lighting conditions without switching cameras.

Up to 100fps Frame Rates: Supports frame rates from 23.976 up to 100fps, enabling meaningful slow-motion capture at 2K resolution.

PL Mount: Industry-standard cinema lens mount compatible with a wide ecosystem of professional cinema glass from manufacturers including ARRI and Zeiss.

Four Color Science Profiles: Offers KineLOG, Kine709, KineColor, and user-defined LUT support for flexible on-set monitoring and post-production grading workflows.

Camera Specifications — Kinefinity KineRAW-MINI

Kinefinity KineRAW-MINI full specifications
SpecDetail
Use CasesDocumentary, Video / Cinematography
TypeOther
SensorSuper 35
Resolution2048 x 1080 (2.2 megapixels effective)
ISO Range80 – 20480
AF SystemManual Focus Only
AF PointsManual focus only
Max Video Resolution2048 x 1080 (2K DCI)
Max Frame Rate100fps
Bit Depth12-bit
Video Color ProfilesKineLOG, Kine709, KineColor, User-defined LUT
Image StabilizationNone

Description — Kinefinity KineRAW-MINI

The Kinefinity KineRAW is a Super 35 cinema camera with a 2048 x 1080 (2K DCI) sensor producing 2.2 megapixels of effective resolution. Its ISO range runs from 80 to 20480, and all footage is captured at 12-bit depth. Frame rate options are extensive, covering 23.976, 24, 25, 29.97, 30, 48, 50, 59.94, 60, 96, and 100fps, supporting slow-motion and standard cinematic acquisition.

The camera offers four color profiles — KineLOG, Kine709, KineColor, and user-defined LUT — to suit different grading pipelines. Lens attachment is via PL mount, and media is recorded to SSD. Connectivity includes two HDMI outputs (720p monitoring), a 3.5mm microphone jack (no phantom power), and Wi-Fi.

There is no autofocus; the system is manual focus only. The body weighs 1,500g and measures 94 x 118 x 168mm, with power supplied by an optional handgrip battery or DC IN (6–19V).

Pros — Kinefinity KineRAW-MINI

  • ✓Wide ISO range from 80 to 20480 offers significant exposure latitude across lighting conditions
  • ✓12-bit recording depth supports robust color grading in post-production
  • ✓Extensive frame rate support up to 100fps, with 96fps as the specified maximum frame rate

Cons — Kinefinity KineRAW-MINI

  • ✗Manual focus only — no autofocus system of any kind is available
  • ✗Maximum video resolution is 2048 x 1080 (2K DCI); no 4K or higher output
  • ✗HDMI monitoring is limited to 720p resolution

Reviews — Kinefinity KineRAW-MINI

Videos — Kinefinity KineRAW-MINI

Kinefinity Terra 6K REVIEW!!! — Mark Moore

Resources & Downloads — Kinefinity KineRAW-MINI

Manuals & Guides

Frequently Asked Questions — Kinefinity KineRAW-MINI

What lenses are compatible with the KineRAW?+
The KineRAW uses a PL mount, which is the industry-standard cinema lens mount. The specifications list PL Mount as the sole lens mount option.
What frame rates does the KineRAW support?+
The camera supports 23.976, 24, 25, 29.97, 30, 48, 50, 59.94, 60, 96, and 100fps. The specified maximum frame rate is 96fps.
What color profiles are available in-camera?+
Four color profiles are available: KineLOG, Kine709, KineColor, and user-defined LUT. This gives shooters options for log-based grading workflows as well as a standard Rec. 709 look.
How is the KineRAW powered?+
Power is supplied via an optional handgrip with battery or through DC IN accepting 6 to 19V. With a 21Wh battery, runtime is approximately 1.5 hours.
Does the KineRAW have autofocus?+
No — the camera is manual focus only. There is no autofocus system, no subject tracking, and no eye tracking.
What monitoring outputs does the KineRAW provide?+
The camera has two HDMI outputs for monitoring at 720p resolution. There is no viewfinder specified in the data.
