Camera Overview — RED Digital Cinema Epic-M Dragon 6K

The RED Epic-M Dragon is a professional cinema camera built around a Super 35 sensor capable of recording up to 6K resolution. Designed for high-end film and television production, it supports frame rates up to 120fps, giving cinematographers the flexibility to capture high-resolution slow-motion sequences alongside standard cinematic frame rates. The camera records in both RAW and ProRes formats to RED MINI-MAG media, offering a choice between maximum image fidelity and more edit-friendly workflows on set.

With a PL Mount lens interface, the Epic-M Dragon integrates seamlessly into established cinema lens ecosystems. Connectivity is well-covered for professional productions, with HDMI, 3G-SDI, and USB 3.0 outputs available for monitoring, transmission, and data transfer. Audio is handled via both a 3.5mm mic input and XLR connections, accommodating everything from run-and-gun setups to fully-crewed productions.

The camera body weighs between 2.26kg and 2.5kg depending on configuration, making it a substantial but manageable option for rigged cinema use. A maximum ISO of 2000 rounds out the core sensitivity specification.

Key Features — RED Digital Cinema Epic-M Dragon 6K

6K Dragon Super 35 Sensor: RED's Dragon sensor captures up to 6K resolution in a Super 35 format, delivering cinematic image quality with wide latitude for post-production reframing and finishing.

High Frame Rate Slow Motion: Supports high frame rate recording at reduced resolutions for slow-motion sequences; at 6K the maximum is lower than 120fps.

REDCODE RAW Recording: Records natively in REDCODE RAW to RED MINI-MAG media, preserving maximum image data for color grading and visual effects work in post-production.

ProRes Recording Option: Supports ProRes recording alongside RAW, giving productions an edit-friendly format for faster on-set review and offline workflows.

PL Mount Interface: Industry-standard PL Mount provides compatibility with a broad range of professional cinema lenses from manufacturers including Zeiss, Cooke, and ARRI.

3G-SDI & HDMI Outputs: Dual monitoring outputs support on-set video village setups, external recorders, and transmission systems in professional production environments.

Camera Specifications — RED Digital Cinema Epic-M Dragon 6K

RED Digital Cinema Epic-M Dragon 6K full specifications
Spec	Detail
Use Cases	Video / Cinematography, Documentary, Studio
Type	Other
Sensor	Super 35
AF System	Manual Focus Only
Max Video Resolution	6K
Storage Media	RED MINI-MAG
Lens Mount	PL Mount

Description — RED Digital Cinema Epic-M Dragon 6K

The RED Epic-M Dragon is a Super 35 format cinema camera capable of capturing footage at up to 6K maximum resolution. It supports frame rates reaching 120fps, making high-speed cinematic work achievable alongside standard production frame rates. The camera records to RED MINI-MAG media in either RAW or ProRes formats, giving productions the flexibility to prioritize image fidelity or workflow efficiency depending on their needs.

The PL Mount lens interface connects the Epic-M Dragon to the wider professional cinema lens ecosystem. On the connectivity side, the camera provides HDMI, 3G-SDI, and USB 3.0 outputs for monitoring and data transfer, while audio is covered by both a 3.5mm mic input and XLR connections. With a body weight ranging from 2.26kg to 2.5kg and a maximum ISO of 2000, the Epic-M Dragon is built for structured, fully-crewed cinema productions where image resolution and recording format flexibility are the primary priorities.

Pros — RED Digital Cinema Epic-M Dragon 6K

✓6K maximum video resolution enables high-resolution cinematic capture and flexible post-production reframing
✓Up to 120fps maximum frame rate supports high-speed slow-motion at the top resolution tier
✓Dual recording formats — RAW and ProRes — offer flexibility between maximum image quality and efficient on-set workflows
✓PL Mount compatibility aligns the camera with the professional cinema lens ecosystem
✓Comprehensive connectivity including HDMI, 3G-SDI, and USB 3.0 supports professional monitoring and data workflows
✓Dual audio inputs (3.5mm mic and XLR) accommodate a wide range of production audio setups

Cons — RED Digital Cinema Epic-M Dragon 6K

✗Maximum ISO of 2000 is relatively modest for a cinema camera, which may limit low-light versatility
✗Exclusively records to RED MINI-MAG media, requiring proprietary storage that adds to overall system cost
✗Body weight of 2.26–2.5kg means additional rigging and support equipment will be necessary for most shooting scenarios
✗Single lens mount option (PL Mount only) limits out-of-the-box compatibility with DSLR or mirrorless lens systems without adapters

Reviews — RED Digital Cinema Epic-M Dragon 6K

Videos — RED Digital Cinema Epic-M Dragon 6K

This 9 Year Old RED Sensor Still Produces INCREDIBLE Images!! — CVP

Resources & Downloads — RED Digital Cinema Epic-M Dragon 6K

Manuals & Guides

User Manual
PDF · 26.5 MB

Frequently Asked Questions — RED Digital Cinema Epic-M Dragon 6K

What recording formats does the RED Epic-M Dragon support?+

The camera supports both RAW and ProRes recording formats. RAW delivers maximum image data for demanding post-production pipelines, while ProRes provides a more immediately usable file format for faster turnaround workflows.

What media does the RED Epic-M Dragon record to?+

The Epic-M Dragon records exclusively to RED MINI-MAG media. This is a proprietary storage format, so budgeting for RED MINI-MAG cards and readers is an essential part of building out a complete system.

What lens mount does this camera use?+

The Epic-M Dragon uses a PL Mount, which is the standard mount for professional cinema lenses. It is not natively compatible with EF, E-mount, or other photographic lens systems without an appropriate adapter.

What are the camera's connectivity options for on-set monitoring?+

The camera offers HDMI, 3G-SDI, and USB 3.0 outputs. The 3G-SDI output is particularly suited to professional on-set monitoring environments, while HDMI provides compatibility with a wide range of consumer and prosumer monitors.

What audio inputs does the RED Epic-M Dragon provide?+

The camera includes both a 3.5mm mic input and XLR audio inputs. The XLR connection supports professional balanced audio from mixers and wireless receivers, while the 3.5mm input offers a lighter-weight option for smaller production setups.

How much does the RED Epic-M Dragon weigh?+

The body weight ranges from 2.26kg to 2.5kg depending on configuration. For most cinema applications, additional rigging, a proper support system, and accessories will increase the overall carrying weight significantly.
